PLS-ZDYM-03 Thermoforming

Short Description:

PLS-ZDYM-03 thermoforming has a parameter storage function, which can switch between different diaphragm materials with one click. Whether it is TPU, PETG or composite diaphragm, it can easily cope with and meet various needs.It uses advanced positive pressure molding technology to make the diaphragm fit the model tightly, and the details of the tooth cusps and accessories are clearly presented, ensuring that the orthodontic model is accurate and correct.


Product Detail

Product Tags

Description

Prismlab PLS-ZDYM-03 thermoforming, with its efficient, accurate and intelligent performance, helps oral orthodontic work to be carried out efficiently and provides reliable support for professional orthodontic treatment.

Its intelligent temperature control system ensures uniform heating to prevent temperature deviation from affecting the molding effect.

Features

1.Positive pressure forming
2.Intelligent temperature control
3.One-touch Switching of different membrane forming parameters

Application

Prismlab PLS-ZDYM-03 thermoforming is mainly used in the field of orthodontics to make invisible orthodontic models.

Parameters

Product Name PLS-ZDYM-03
Forming Pressure 0 bar~6bar
Single Forming Time 1min~1.5min
Compatible Model Types 3D Printed Models,Plaster Models
Compatible Membrane Size Round Membranes:D120mm,D125mm
Square Membranes:127mmx127mm
Compatible Membrane Types TPU,PETG
Power 800W
Overall Dimensions 426mmx425mmx512mm
Weight 50Kg
Power Supply AC220V/110V
