ACTA-D Trimming Machine

Short Description:

Prismlab ACTA-D trimming machine’s five-axis cutting system only takes about 30 seconds to complete a single dental model cutting, and the dedicated positioning plate makes loading and unloading more convenient. The combination of intelligent algorithms and automated equipment provides a super-intelligent solution for invisible braces manufacturing, which is easy for novices to use.


Product Detail

Product Tags

Description

Prismlab ACTA-D trimming machine perfectly compatible with 3Shape design software, batch import of dental models, one-click labeling, hollowing, positioning structure addition, gum line generation and other operations, and batch export of processed model processing files and 3D printing models.

Features

1.Adapt to mainstream design softwaresuch as 3shape, etc.
2.Prismlab ACTA-D five-axis trimming system
3.Combination of intelligent algorithmand equipment automation

Application

Prismlab ACTA-D trimming machine is mainly used in the processing and production of clear aligner. It trimming the clear aligner pressed on the dental model from the whole dental sheet, with a high degree of matching and high degree of customization.

Parameters

Product Name ACTA-D
Xaxis 90mm
Yaxis 90mm
Z axis 108mm
Aaxis -30/+120°
Caxis +360°
Feed speed of X/Y/Z 0-5,000mm/min
Rotational speed of the spindle 30,000 r/min
Equipment volume 550mm*550mm*550mm
Voltage 220V
Power 1.5KWh
Weight 65KG
